300mm² PREMFLEX 90 RADA 1KV 300 BLACK 1 Core Cable x Per Metre Class 6

This cable offers excellent flexibility and current carrying capacity. Radaflex™ is fast becoming the standard cable for many in the Power Generation Industry. Its outer sheath is oil and flame retardant. Radaflex™ Class 6 cable offers extra carrying capacity over standard Powerlock cables of the same CSA up to 783Amps on 300mm² an aditional 90Amps over H07RN-F.

PREMFLEX 90 cable is suitable for all types of low voltage industrial-type connections, in urban grids, building installations, etc.
Its high flexibility makes the installation process substantially easier and, as a result, is particularly suitable for use in difficult layouts. It can be buried or installed in a tube as well as outdoors without requiring additional protection.
Conductor
Electrolytic annealed copper, class 6 (high flexibility) according to EN 60228 and IEC 60228.
Insulation
Flexible PVC high service temperature type TI3 according to EN 50363-3 up to 70 mm2. Cross-linked polyethylene, type XLPE according to IEC 60502-1 from 95 mm2.
The standard identification of insulated conductors according to HD 308 is the following:
1 x           Natural
Outer sheath
Flexible and oil resistant PVC, type TM5 according to EN 50363-4-1. Black or orange colour.

• BS5467 and BS6500 and BS6007
• Finely Stranded Plain Annealed Copper
• CPE (Chlorinated Polyethylene) rubber compound
• IEC 60502, UL 1581
• IEC 332-1 Flame Test
• VDE 0472 / 0283 / 0250 (ASTM N2)
• Class 6 stranding based on VDE 0295
• 72/33/EEC and 92/59/EEC and 93/68/EEC
• 783Amps Open Air
