PowerBOX 125Amp 3pH+N+E 400V CASE RACK 19" 9U on Wheels

PowerBOX 125Amp 3pH+N+E 400V “ CASE RACK  on Wheels with Skate

• Professional standard 19" rack case, 9U height, made of 10mm thick plywood with black scratch-resistant outer foil.
• 2 front / rear covers.
• 8 handles with rubber grips
• 8 butterfly closures
• 8 rounded corners
• 4 wheels Ø 100 mm in rubber (2 with brake) mounted on skate.
• 2 component-holder panels (front/rear) in PVC-CAW black color 10mm

Made in Italy.

PowerBOX 125Amp 3pH+N+E 400V on case rack 19” 9U, PBF125P9U

Equipment ( rear ):
1 x 125Amp 3P+N+E 5p 6h 400V IP67 appliance inlet black color ( IN ).
1 x external earthing point M8.
3 x 16Amp 1pH+N+E  6h 230V IP44 panel socket black color ( OUT ) + 3 x led green color.
3 x 16Amp 3pH+N+E  6h 400V IP44 panel socket black color ( OUT ) + 3 x led green color.
2 x 32Amp 3pH+N+E  6h 400V IP44 panel socket black color ( OUT ) + 2 x led green color.
protection and instrumentation devices ( front ):
1 fuse switch 3pN 10,3x38mm. ( F1 ) + 1 three-phase voltage indicator light red ( L1-L2-L3 ).
1 MCB 125Amp 4p-C 10.000A ( MAIN ).
1 fuse switch 3pN 10,3x38mm. ( F2 ) + 1 flush-mount LCD multimeter (backlight icon LCD; http://www.lovatoelectric.co.uk/DMG600/DMG600/snp ).
3 x RCBO 16Amp 1pN-C 6.000A IΔn=0,03A Type A ( 3 x CEE-17 16amp 3p ).
3 x MCB 16Amp 4p-C 6.000A & RCD 40amp 4p IΔn=0,03A Type A  ( 3 x CEE-17 16amp 5p ).
2 x MCB 32Amp 4p-C 6.000A & RCD 40amp 4p IΔn=0,03A Type A  ( 2 x CEE-17 32amp 5p ).
Nominal data:
IEC 61439-1 & 2, UE=400V 3pH+N+E, fn=50Hz, InA=125amp, IP=44, RDF=97%, Icc=6.000A, insulation class I.
Note:
- Schneider Electric brand fuse switch, MCB, RCD and RCBO.
- wired, tested and ready for the final installation.

  CE DECLARATION OF CONFORMITY
LOW VOLTAGE SWITCHGEAR AND CONTROLGEAR ASSEMBLIES IN COMPLIANCE
WITH THE STANDARD IEC 61439-1/2 (EN 61439-1/2)

The CE marking is required for many products. It:
·         shows that the manufacturer has checked that these products meet EU safety, health or environmental requirements
·         is an indicator of a product’s compliance with EU legislation
·         allows the free movement of products within the European market


Available in many differennt configurations, built to your individual specifications. Call us to build yours.
