PowerBOX 250Amp 3pH+N+E 400V CASE RACK 19"15U 8 x Socapex 19 Pin Panel Sockets

PowerBox Rack Standard 250Amp 3pH+N+E 400V 19" RACK FLIGHTCASE 15U  - Energy on wheels



• Professional standard 19" rack case, 15U height, made of 10mm thick plywood with black scratch-resistant outer foil.
• 2 front / rear covers.
• 8 handles with rubber grips
• 8 butterfly closures
• 8 rounded corners
• 4 wheels Ø 100 mm in rubber (2 with brake) mounted on skate.
• 2 component-holder panels (front/rear) in PVC-CAW black color 10mm thickness (V0-UL 94) with sealing gaskets.
• Dimensions: W535 x H1070 x D820mm. about (included lids).
• Weight: 90kg. about (equipped).

Incoming : 5 x Powerlock powerSYNTAX drain 480amp L1-L2-L3-N-E 400V IP67.
Loop (through) : 5 x Powerlock powerSYNTAX source 480amp L1-L2-L3-N-E 400V IP67 with dust caps IP53.
Main OUT : 1 MCB 250amp 4p 25kA.
Outgoing : 8 x SYNTAX Soocapex SSX 19p IP67
Outgoing Protection: 48  x RCBO 16amp 1pN-C 6.000A Idn 0,03A Type A
Installed accessories :
1 analogic voltmeter + 1 selector switch +
1 three-phase red led (IN, 1 fuse switch 3pN 10,3x38mm. / F1),
48 green leds (OUT), 1 LCD multimer (1 fuse switch 3pN 10,3x38mm. / F2).

Technical data : IEC 61439-1 & 2, Ue: 400V 3pH+N+E, fn: 50Hz, InA (Incoming/Loop): 400amp, InA (Main OUT): 250amp, Icc: 6.000A, RDF (IN): 61%, RDF (MAIN): 97%, IP: 44, Electrical insulation class: I (first).

Nominal data: IEC 61439-1 & 2, Ue: 400V 3pH+N+E, fn: 50Hz, InA: 400amp, Icc: 6.000A, RDF: 61%, IP: 44, Insulation class: I.



CE DECLARATION OF CONFORMITY
LOW VOLTAGE SWITCHGEAR AND CONTROLGEAR ASSEMBLIES IN COMPLIANCE
WITH THE STANDARD IEC 61439-1/2 (EN 61439-1/2)

The CE marking is required for many products. It:
·         shows that the manufacturer has checked that these products meet EU safety, health or environmental requirements
·         is an indicator of a product’s compliance with EU legislation
·         allows the free movement of products within the European market


Available in many differennt configurations, built to your individual specifications. Call us to build yours.
