PowerBOX 63Amp 3pH+N+E 400V CASE RACK 19” 15U 6 x Socapex

PowerBOX 63Amp 3pH+N+E 400V “CASE RACK 19” 15U 6 x Socapex



• Professional standard 19" rack case, 15U height, made of 10mm thick plywood with black scratch-resistant outer foil.
• 2 front / rear covers.
• 8 handles with rubber grips
• 8 butterfly closures
• 8 rounded corners
• 4 wheels Ø 100 mm in rubber (2 with brake) mounted on skate.
• 2 component-holder panels (front/rear) in PVC-CAW black color 10mm thickness (V0-UL 94) with sealing gaskets.

REAR (incoming & outgoing):
1 x C-Form 63Amp 5p 6h 400V IP67 appliance inlet black (IN POWER 63/3).
12 x C-Form 16Amp 3p 6h 230V IP44 panel socket black (12 x C-Form 16/1).
6 x SYNTAX SSX 19p IP67 female panel connector (6 x SOCA 6 channels).
2 x BS 13Amp 3p 230V IP44 panel socket (SERVICE).
1 free unit for DMX buffer installation.
FRONT  (protection devices & instrumentation):
1 fuse switch 3pN 10,3x38mm. (F1) + 1 three-phase led red color (IN; L1-L2-L3).
1 MCB 63Amp 4p-C 6.000A (MAIN OUT).
12 x RCBO 16Amp 1pN-C 6.000A Idn 0,03A AC (12 x C-Form 16amp single-phase).
36 x RCBO 16Amp 1pN-C 6.000A Idn 0,03A AC (6 x SYNTAX SSX 19p / SOCA 6 channels).
1 X  RCBO 16Amp 1pN-C 6.000A Idn 0,03A AC (2 x BS 13amp single-phase).

TECHNICAL DATA: IEC 61439-1 & 2, Ue: 400V 3pH+N+E, fn: 50Hz, InA: 63amp, Icc: 6.000A, RDF: 26%, IP: 32, Insulation class: I.

 Note:
- Schneider Electric brand fuse switch, MCB, RCD and RCBO.
- wired, tested and ready for the final installation.   CE DECLARATION OF CONFORMITY
LOW VOLTAGE SWITCHGEAR AND CONTROLGEAR ASSEMBLIES IN COMPLIANCE
WITH THE STANDARD IEC 61439-1/2 (EN 61439-1/2)

The CE marking is required for many products. It:
·         shows that the manufacturer has checked that these products meet EU safety, health or environmental requirements
·         is an indicator of a product’s compliance with EU legislation
·         allows the free movement of products within the European market


Available in many differennt configurations, built to your individual specifications. Call us to build yours.
