Powersafe Powerlock Full Set of 5 x Panel Mount Source 800A Connectors T8

Our No: 8255
Manufacturer No: DZ-SPS-T8-SET5-EU
Stock Available: Out of Stock
Next day delivery

Volume Discounts

Units % Price per unit
2 5% £216.03
£227.40
£272.88 (inc VAT)

Full set of 5 x 800A Panel Mount Source T8 Connectors, includes Earth Green, Neutral Blue, L1 Brown, L2 Black and L3 Grey. Each connector comes fully assembled with a gasket, M12 threaded post and M12 nut and spring washer.

About The Connectors
The 800A connectors are manufactured using copper with silver plating and is capable of running between 600 – 800Amps. They can be terminated using any standard cable lug, and are available for all three phases plus Neutral and Earth. They have the same mechanical locking system as their inline counterparts; secure coupling of plug and socket is achieved through an innovative mechanical locking system that disengages with a simple release key.

Both the 500A or 800A rated Panel Mount Source Connectors can mate with any sized Line Drain Connector (including those made by other manufacturers). The cable size determines the amperage available.

Safety & Performance Features
•    Mechanically keyed to eliminate the possibility of cross mating
•    Secondary locking prevents unintentional uncoupling under load
•    Finger-proof protection against electric shock IP2X
•    Waterproof & Dustproof to IP67 rated
•    Colour coded for easy identification of three phase electricity
•    Innovative contact band allows higher rating (400A > 500A, 660A > 800A)
•    Contact band cannot come out
•    High impact insulator (no glass used & flame retardant)
•    Field installation no special tools required
•    Gasket allows watertight securing to panel distribution boards

Brand:

Powersafe

Type:

Panel Mount Source Connectors

Amperage:

800A

Gender:

Source

Line:

Set of 5

Colour Group:

EU

Termination (Cable):

T8 Threaded Post Termination

Powerlock Colour:

Set of 5 Colours
